''' <summary>
''' Rotates an image by 90 degrees clockwise.
''' </summary>
Public Class ImageOrthogonalClockwiseRotationCommand
    Inherits Vintasoft.Imaging.ImageProcessing.Transforms.ImageTransformationBasedCommand

    ''' <summary>
    ''' Initializes a new instance of the <see cref="ImageOrthogonalClockwiseRotationCommand"/> class.
    ''' </summary>
    Public Sub New()
        MyBase.New()
    End Sub



    ''' <summary>
    ''' Gets the name of the command.
    ''' </summary>
    Public Overrides ReadOnly Property Name() As String
        Get
            Return "Rotate image orthogonal clockwise."
        End Get
    End Property



    ''' <summary>
    ''' Creates a new <see cref="ImageOrthogonalClockwiseRotationCommand"/> that is a copy of the current instance.
    ''' </summary>
    ''' <returns>A new <see cref="ImageOrthogonalClockwiseRotationCommand"/> that is a copy of this instance.</returns>
    Public Overrides Function Clone() As Object
        Dim command As New ImageOrthogonalClockwiseRotationCommand()
        CopyTo(command)
        Return command
    End Function


    ''' <summary>
    ''' Creates the point transformation that is used for transforming points from
    ''' the destination image space to the source image space.
    ''' </summary>
    ''' <param name="sourceImageSize">Size of source image.</param>
    ''' <returns>The point transformation that is used for transforming points from
    ''' the destination image space to the source image space.</returns>
    Protected Overrides Function CreateTransform(sourceImageSize As Vintasoft.Imaging.VintasoftIntSize) As Vintasoft.Imaging.VintasoftPointTransform
        ' create transform, that defines image transformation
        Return New ClockwiseOrthogonalRotationTransform(sourceImageSize)
    End Function

    ''' <summary>
    ''' Returns size of result image.
    ''' </summary>
    ''' <param name="sourceImageSize">Size of source image.</param>
    ''' <returns>Size of result image.</returns>
    Protected Overrides Function GetResultImageSize(sourceImageSize As Vintasoft.Imaging.VintasoftIntSize) As Vintasoft.Imaging.VintasoftIntSize
        ' calculate transformed image size
        ' for this example it is just image width and heigth swap
        Return New Vintasoft.Imaging.VintasoftIntSize(sourceImageSize.Height, sourceImageSize.Width)
    End Function

End Class

''' <summary>
''' Rotates the point, which is represented by <see cref="Vintasoft.Imaging.VintasoftPoint"/>
''' structure, by 90 degrees clockwise.
''' </summary>
''' <remarks>
''' For this example we need only one transform method, so other methods are not implemented.
''' </remarks>
Public Class ClockwiseOrthogonalRotationTransform
    Inherits Vintasoft.Imaging.VintasoftPointTransform

    ''' <summary>
    ''' Coordinate system size.
    ''' </summary>
    Private _size As Vintasoft.Imaging.VintasoftIntSize



    ''' <summary>
    ''' Initializes a new instance of the <see cref="ClockwiseOrthogonalRotationTransform"/> class.
    ''' </summary>
    ''' <param name="size">Coordinate system size.</param>
    Public Sub New(size As Vintasoft.Imaging.VintasoftIntSize)
        _size = size
    End Sub



    ''' <summary>
    ''' Gets a value indicating whether this transform is invertible.
    ''' </summary>
    ''' <value>
    ''' <b>true</b> if this transform is invertible; otherwise, <b>false</b>.
    ''' </value>
    ''' <remarks>
    ''' Implementations of the <see cref="GetInverseTransform" /> method should throw an exception
    ''' if this transform is not invertible.
    ''' </remarks>
    ''' <seealso cref="GetInverseTransform" />
    Public Overrides ReadOnly Property IsInvertible() As Boolean
        Get
            Return False
        End Get
    End Property



    ''' <summary>
    ''' Returns the inverse transform.
    ''' </summary>
    Public Overrides Function GetInverseTransform() As Vintasoft.Imaging.VintasoftPointTransform
        Throw New System.NotImplementedException()
    End Function

    ''' <summary>
    ''' Transforms the specified point coordinates by this <see cref="Vintasoft.Imaging.VintasoftPointTransform"/>.
    ''' </summary>
    ''' <param name="x">The X coordinate to transform.</param>
    ''' <param name="y">The Y coordinate to transform.</param>
    Public Overrides Sub TransformPoint(ByRef x As Double, ByRef y As Double)
        Dim oldX As Double = x
        x = y
        y = _size.Height - oldX
    End Sub

    ''' <summary>
    ''' Transforms the specified point by this <see cref="Vintasoft.Imaging.VintasoftPointScaleTransform"/> and
    ''' returns the result.
    ''' </summary>
    ''' <param name="point">The point to transform.</param>
    ''' <returns>
    ''' The result of transforming <i>point</i> by this <see cref="Vintasoft.Imaging.PointFScaleTransform"/>.
    ''' </returns>
    Public Overrides Function TransformPoint(point As Vintasoft.Imaging.VintasoftPoint) As Vintasoft.Imaging.VintasoftPoint
        Throw New System.NotImplementedException()
    End Function

    ''' <summary>
    ''' Transforms the specified points by this <see cref="Vintasoft.Imaging.VintasoftPointScaleTransform"/>.
    ''' </summary>
    ''' <param name="points">The <i>points</i> to transform.
    ''' The original points in the array are replaced by their transformed values.</param>
    Public Overrides Sub TransformPoints(points As Vintasoft.Imaging.VintasoftPoint())
        Throw New System.NotImplementedException()
    End Sub

    ''' <summary>
    ''' Transforms the specified vector coordinates by this <see cref="Vintasoft.Imaging.VintasoftPointTransform"/>.
    ''' </summary>
    ''' <param name="x">The X coordinate to transform.</param>
    ''' <param name="y">The Y coordinate to transform.</param>
    Public Overrides Sub TransformVector(ByRef x As Double, ByRef y As Double)
        Throw New System.NotImplementedException()
    End Sub

    ''' <summary>
    ''' Transforms the specified vector by this <see cref="Vintasoft.Imaging.VintasoftPointScaleTransform"/>.
    ''' </summary>
    ''' <param name="vector">The vector to transform.</param>
    ''' <returns>
    ''' The result of transforming <i>vector</i> by this <see cref="Vintasoft.Imaging.VintasoftPointScaleTransform"/>.
    ''' </returns>
    Public Overrides Function TransformVector(vector As Vintasoft.Imaging.VintasoftPoint) As Vintasoft.Imaging.VintasoftPoint
        Throw New System.NotImplementedException()
    End Function

    ''' <summary>
    ''' Transforms the specified vectors by this <see cref="Vintasoft.Imaging.VintasoftPointScaleTransform"/>.
    ''' </summary>
    ''' <param name="vectors">The <i>vectors</i> to transform.
    ''' The original vectors in the array are replaced by their transformed values.</param>
    Public Overrides Sub TransformVectors(vectors As Vintasoft.Imaging.VintasoftPoint())
        Throw New System.NotImplementedException()
    End Sub

End Class

/// <summary>
/// Rotates an image by 90 degrees clockwise.
/// </summary>
public class ImageOrthogonalClockwiseRotationCommand :
    Vintasoft.Imaging.ImageProcessing.Transforms.ImageTransformationBasedCommand
{

    /// <summary>
    /// Initializes a new instance of the <see cref="ImageOrthogonalClockwiseRotationCommand"/> class.
    /// </summary>
    public ImageOrthogonalClockwiseRotationCommand()
        : base()
    {
    }



    /// <summary>
     /// Gets the name of the command.
     /// </summary>
    public override string Name
    {
        get
        {
            return "Rotate image orthogonal clockwise.";
        }
    }



    /// <summary>
    /// Creates a new <see cref="ImageOrthogonalClockwiseRotationCommand"/> that is a copy of the current instance.
    /// </summary>
    /// <returns>A new <see cref="ImageOrthogonalClockwiseRotationCommand"/> that is a copy of this instance.</returns>
    public override object Clone()
    {
        ImageOrthogonalClockwiseRotationCommand command = new ImageOrthogonalClockwiseRotationCommand();
        CopyTo(command);
        return command;
    }


    /// <summary>
    /// Creates the point transformation that is used for transforming points from
    /// the destination image space to the source image space.
    /// </summary>
    /// <param name="sourceImageSize">Size of source image.</param>
    /// <returns>The point transformation that is used for transforming points from
    /// the destination image space to the source image space.</returns>
    protected override Vintasoft.Imaging.VintasoftPointTransform CreateTransform(Vintasoft.Imaging.VintasoftIntSize sourceImageSize)
    {
        // create transform, that defines image transformation
        return new ClockwiseOrthogonalRotationTransform(sourceImageSize);
    }

    /// <summary>
    /// Returns size of result image.
    /// </summary>
    /// <param name="sourceImageSize">Size of source image.</param>
    /// <returns>Size of result image.</returns>
    protected override Vintasoft.Imaging.VintasoftIntSize GetResultImageSize(Vintasoft.Imaging.VintasoftIntSize sourceImageSize)
    {
        // calculate transformed image size
        // for this example it is just image width and heigth swap
        return new Vintasoft.Imaging.VintasoftIntSize(sourceImageSize.Height, sourceImageSize.Width);
    }

}

/// <summary>
/// Rotates the point, which is represented by <see cref="Vintasoft.Imaging.VintasoftPoint"/>
/// structure, by 90 degrees clockwise.
/// </summary>
/// <remarks>
/// For this example we need only one transform method, so other methods are not implemented.
/// </remarks>
public class ClockwiseOrthogonalRotationTransform : Vintasoft.Imaging.VintasoftPointTransform
{

    /// <summary>
    /// Coordinate system size.
    /// </summary>
    Vintasoft.Imaging.VintasoftIntSize _size;



    /// <summary>
    /// Initializes a new instance of the <see cref="ClockwiseOrthogonalRotationTransform"/> class.
    /// </summary>
    /// <param name="size">Coordinate system size.</param>
    public ClockwiseOrthogonalRotationTransform(Vintasoft.Imaging.VintasoftIntSize size)
    {
        _size = size;
    }



    /// <summary>
    /// Gets a value indicating whether this transform is invertible.
    /// </summary>
    /// <value>
    /// <b>true</b> if this transform is invertible; otherwise, <b>false</b>.
    /// </value>
    /// <remarks>
    /// Implementations of the <see cref="GetInverseTransform" /> method should throw an exception
    /// if this transform is not invertible.
    /// </remarks>
    /// <seealso cref="GetInverseTransform" />
    public override bool IsInvertible
    {
        get
        {
            return false;
        }
    }



    /// <summary>
    /// Returns the inverse transform.
    /// </summary>
    public override Vintasoft.Imaging.VintasoftPointTransform GetInverseTransform()
    {
        throw new System.NotImplementedException();
    }

    /// <summary>
    /// Transforms the specified point coordinates by this <see cref="Vintasoft.Imaging.VintasoftPointTransform"/>.
    /// </summary>
    /// <param name="x">The X coordinate to transform.</param>
    /// <param name="y">The Y coordinate to transform.</param>
    public override void TransformPoint(ref double x, ref double y)
    {
        double oldX = x;
        x = y;
        y = _size.Height - oldX;
    }

    /// <summary>
    /// Transforms the specified point by this <see cref="Vintasoft.Imaging.VintasoftPointScaleTransform"/> and
    /// returns the result.
    /// </summary>
    /// <param name="point">The point to transform.</param>
    /// <returns>
    /// The result of transforming <i>point</i> by this <see cref="Vintasoft.Imaging.PointFScaleTransform"/>.
    /// </returns>
    public override Vintasoft.Imaging.VintasoftPoint TransformPoint(Vintasoft.Imaging.VintasoftPoint point)
    {
        throw new System.NotImplementedException();
    }

    /// <summary>
    /// Transforms the specified points by this <see cref="Vintasoft.Imaging.VintasoftPointScaleTransform"/>.
    /// </summary>
    /// <param name="points">The <i>points</i> to transform.
    /// The original points in the array are replaced by their transformed values.</param>
    public override void TransformPoints(Vintasoft.Imaging.VintasoftPoint[] points)
    {
        throw new System.NotImplementedException();
    }

    /// <summary>
    /// Transforms the specified vector coordinates by this <see cref="Vintasoft.Imaging.VintasoftPointTransform"/>.
    /// </summary>
    /// <param name="x">The X coordinate to transform.</param>
    /// <param name="y">The Y coordinate to transform.</param>
    public override void TransformVector(ref double x, ref double y)
    {
        throw new System.NotImplementedException();
    }

    /// <summary>
    /// Transforms the specified vector by this <see cref="Vintasoft.Imaging.VintasoftPointScaleTransform"/>.
    /// </summary>
    /// <param name="vector">The vector to transform.</param>
    /// <returns>
    /// The result of transforming <i>vector</i> by this <see cref="Vintasoft.Imaging.VintasoftPointScaleTransform"/>.
    /// </returns>
    public override Vintasoft.Imaging.VintasoftPoint TransformVector(Vintasoft.Imaging.VintasoftPoint vector)
    {
        throw new System.NotImplementedException();
    }

    /// <summary>
    /// Transforms the specified vectors by this <see cref="Vintasoft.Imaging.VintasoftPointScaleTransform"/>.
    /// </summary>
    /// <param name="vectors">The <i>vectors</i> to transform.
    /// The original vectors in the array are replaced by their transformed values.</param>
    public override void TransformVectors(Vintasoft.Imaging.VintasoftPoint[] vectors)
    {
        throw new System.NotImplementedException();
    }

}
