''' <summary>
''' Visual tool that draws static text (filename, current zoom factor) over image in
''' image viewer and draws a frame around image in image viewer:
''' </summary>
Public Class GraphicObjectToolExample
    Inherits Vintasoft.Imaging.UI.VisualTools.GraphicObjects.GraphicObjectTool

    #Region "Fields"

    ''' <summary>
    ''' The graphic object that draws a filename over the image in image viewer.
    ''' </summary>
    Private _fileNameGraphicObject As New Vintasoft.Imaging.UI.VisualTools.GraphicObjects.TextGraphicObject()

    ''' <summary>
    ''' The graphic object that draws image zoom factor over the image in image viewer.
    ''' </summary>
    Private _zoomGraphicObject As New Vintasoft.Imaging.UI.VisualTools.GraphicObjects.TextGraphicObject()

    ''' <summary>
    ''' The graphic object that draws a frame around image in image viewer.
    ''' </summary>
    Private _borderGraphicObject As New Vintasoft.Imaging.UI.VisualTools.GraphicObjects.RectangularGraphicObject()

    #End Region



    #Region "Constructors"

    ''' <summary>
    ''' Initializes a new instance of the <see cref="GraphicObjectToolExample"/> class.
    ''' </summary>
    Public Sub New()
        _fileNameGraphicObject.TextAnchor = Vintasoft.Imaging.AnchorType.Top
        _fileNameGraphicObject.FontBrush = System.Drawing.Brushes.Salmon
        _fileNameGraphicObject.Font = New System.Drawing.Font("Arial", 24)
        GraphicObjectCollection.Add(_fileNameGraphicObject)

        _zoomGraphicObject.TextAnchor = Vintasoft.Imaging.AnchorType.Bottom Or Vintasoft.Imaging.AnchorType.Right
        _zoomGraphicObject.FontBrush = System.Drawing.Brushes.Lime
        _zoomGraphicObject.Font = New System.Drawing.Font("Arial", 20)
        GraphicObjectCollection.Add(_zoomGraphicObject)

        _borderGraphicObject.PointTransform = New Vintasoft.Imaging.UI.VisualTools.PixelsToImageViewerPointFTransform()
        _borderGraphicObject.Pen = New System.Drawing.Pen(System.Drawing.Color.FromArgb(128, System.Drawing.Color.Lime), 10)
        GraphicObjectCollection.Add(_borderGraphicObject)
    End Sub

    #End Region



    #Region "Methods"

    ''' <summary>
    ''' Raises the <see cref="Vintasoft.Imaging.UI.VisualTools.VisualTool.Activated" /> event.
    ''' </summary>
    Protected Overrides Sub OnActivated(e As System.EventArgs)
        MyBase.OnActivated(e)
        AddHandler ImageViewer.ZoomChanged, New System.EventHandler(Of Vintasoft.Imaging.UI.ZoomChangedEventArgs)(AddressOf ImageViewer_ZoomChanged)
        AddHandler ImageViewer.ClientSizeChanged, New System.EventHandler(AddressOf ImageViewer_ClientSizeChanged)
        AddHandler ImageViewer.ImageLoaded, New System.EventHandler(Of Vintasoft.Imaging.ImageLoadedEventArgs)(AddressOf ImageViewer_ImageLoaded)

        UpdateGraphicObjects()
    End Sub

    ''' <summary>
    ''' Raises the <see cref="Vintasoft.Imaging.UI.VisualTools.VisualTool.Deactivated" /> event.
    ''' </summary>
    Protected Overrides Sub OnDeactivated(e As System.EventArgs)
        MyBase.OnDeactivated(e)

        RemoveHandler ImageViewer.ZoomChanged, AddressOf ImageViewer_ZoomChanged
        RemoveHandler ImageViewer.ClientSizeChanged, AddressOf ImageViewer_ClientSizeChanged
        RemoveHandler ImageViewer.ImageLoaded, AddressOf ImageViewer_ImageLoaded
    End Sub

    ''' <summary>
    ''' Updates the graphic objects.
    ''' </summary>
    Private Sub UpdateGraphicObjects()
        _fileNameGraphicObject.Rectangle = ImageViewer.ClientRectangle
        _zoomGraphicObject.Rectangle = ImageViewer.ClientRectangle
        _zoomGraphicObject.Text = String.Format("Zoom: {0}", ImageViewer.Zoom)

        Dim image As Vintasoft.Imaging.VintasoftImage = ImageViewer.Image
        If image Is Nothing Then
            _fileNameGraphicObject.Text = String.Empty
            _borderGraphicObject.Rectangle = System.Drawing.Rectangle.Empty
        Else
            Dim info As Vintasoft.Imaging.ImageSourceInfo = image.SourceInfo
            If String.IsNullOrEmpty(info.Filename) Then
                _fileNameGraphicObject.Text = String.Empty
            Else
                Dim text As String = System.IO.Path.GetFileName(info.Filename)
                If info.PageCount > 1 Then
                    text += String.Format(" (Page {0}/{1})", info.PageIndex + 1, info.PageCount)
                End If
                _fileNameGraphicObject.Text = text
            End If

            _borderGraphicObject.Rectangle = New System.Drawing.RectangleF(0, 0, image.Width, image.Height)
        End If
    End Sub

    ''' <summary>
    ''' Handles the ClientSizeChanged event of the ImageViewer control.
    ''' </summary>
    Private Sub ImageViewer_ClientSizeChanged(sender As Object, e As System.EventArgs)
        UpdateGraphicObjects()
    End Sub

    ''' <summary>
    ''' Handles the ZoomChanged event of the ImageViewer control.
    ''' </summary>
    Private Sub ImageViewer_ZoomChanged(sender As Object, e As Vintasoft.Imaging.UI.ZoomChangedEventArgs)
        UpdateGraphicObjects()
    End Sub

    ''' <summary>
    ''' Handles the ImageLoaded event of the ImageViewer control.
    ''' </summary>
    Private Sub ImageViewer_ImageLoaded(sender As Object, e As Vintasoft.Imaging.ImageLoadedEventArgs)
        UpdateGraphicObjects()
    End Sub

    #End Region

End Class

/// <summary>
/// Visual tool that draws static text (filename, current zoom factor) over image in
/// image viewer and draws a frame around image in image viewer:
/// </summary>
public class GraphicObjectToolExample :
    Vintasoft.Imaging.UI.VisualTools.GraphicObjects.GraphicObjectTool
{

    #region Fields

    /// <summary>
    /// The graphic object that draws a filename over the image in image viewer.
    /// </summary>
    Vintasoft.Imaging.UI.VisualTools.GraphicObjects.TextGraphicObject _fileNameGraphicObject =
        new Vintasoft.Imaging.UI.VisualTools.GraphicObjects.TextGraphicObject();

    /// <summary>
    /// The graphic object that draws image zoom factor over the image in image viewer.
    /// </summary>
    Vintasoft.Imaging.UI.VisualTools.GraphicObjects.TextGraphicObject _zoomGraphicObject =
        new Vintasoft.Imaging.UI.VisualTools.GraphicObjects.TextGraphicObject();

    /// <summary>
    /// The graphic object that draws a frame around image in image viewer.
    /// </summary>
    Vintasoft.Imaging.UI.VisualTools.GraphicObjects.RectangularGraphicObject _borderGraphicObject =
        new Vintasoft.Imaging.UI.VisualTools.GraphicObjects.RectangularGraphicObject();

    #endregion



    #region Constructors

    /// <summary>
    /// Initializes a new instance of the <see cref="GraphicObjectToolExample"/> class.
    /// </summary>
    public GraphicObjectToolExample()
    {
        _fileNameGraphicObject.TextAnchor = Vintasoft.Imaging.AnchorType.Top;
        _fileNameGraphicObject.FontBrush = System.Drawing.Brushes.Salmon;
        _fileNameGraphicObject.Font = new System.Drawing.Font("Arial", 24);
        GraphicObjectCollection.Add(_fileNameGraphicObject);

        _zoomGraphicObject.TextAnchor =
            Vintasoft.Imaging.AnchorType.Bottom | Vintasoft.Imaging.AnchorType.Right;
        _zoomGraphicObject.FontBrush = System.Drawing.Brushes.Lime;
        _zoomGraphicObject.Font = new System.Drawing.Font("Arial", 20);
        GraphicObjectCollection.Add(_zoomGraphicObject);

        _borderGraphicObject.PointTransform =
            new Vintasoft.Imaging.UI.VisualTools.PixelsToImageViewerPointFTransform();
        _borderGraphicObject.Pen = new System.Drawing.Pen(
            System.Drawing.Color.FromArgb(128, System.Drawing.Color.Lime), 10);
        GraphicObjectCollection.Add(_borderGraphicObject);
    }

    #endregion



    #region Methods

    /// <summary>
    /// Raises the <see cref="Vintasoft.Imaging.UI.VisualTools.VisualTool.Activated" /> event.
    /// </summary>
    protected override void OnActivated(System.EventArgs e)
    {
        base.OnActivated(e);
        ImageViewer.ZoomChanged +=
            new System.EventHandler<Vintasoft.Imaging.UI.ZoomChangedEventArgs>(ImageViewer_ZoomChanged);
        ImageViewer.ClientSizeChanged += new System.EventHandler(ImageViewer_ClientSizeChanged);
        ImageViewer.ImageLoaded +=
            new System.EventHandler<Vintasoft.Imaging.ImageLoadedEventArgs>(ImageViewer_ImageLoaded);

        UpdateGraphicObjects();
    }

    /// <summary>
    /// Raises the <see cref="Vintasoft.Imaging.UI.VisualTools.VisualTool.Deactivated" /> event.
    /// </summary>
    protected override void OnDeactivated(System.EventArgs e)
    {
        base.OnDeactivated(e);

        ImageViewer.ZoomChanged -= ImageViewer_ZoomChanged;
        ImageViewer.ClientSizeChanged -= ImageViewer_ClientSizeChanged;
        ImageViewer.ImageLoaded -= ImageViewer_ImageLoaded;
    }

    /// <summary>
    /// Updates the graphic objects.
    /// </summary>
    void UpdateGraphicObjects()
    {
        _fileNameGraphicObject.Rectangle = ImageViewer.ClientRectangle;
        _zoomGraphicObject.Rectangle = ImageViewer.ClientRectangle;
        _zoomGraphicObject.Text = string.Format("Zoom: {0}", ImageViewer.Zoom);

        Vintasoft.Imaging.VintasoftImage image = ImageViewer.Image;
        if (image == null)
        {
            _fileNameGraphicObject.Text = string.Empty;
            _borderGraphicObject.Rectangle = System.Drawing.Rectangle.Empty;
        }
        else
        {
            Vintasoft.Imaging.ImageSourceInfo info = image.SourceInfo;
            if (string.IsNullOrEmpty(info.Filename))
                _fileNameGraphicObject.Text = string.Empty;
            else
            {
                string text = System.IO.Path.GetFileName(info.Filename);
                if (info.PageCount > 1)
                    text += string.Format(" (Page {0}/{1})", info.PageIndex + 1, info.PageCount);
                _fileNameGraphicObject.Text = text;
            }

            _borderGraphicObject.Rectangle = new System.Drawing.RectangleF(0, 0, image.Width, image.Height);
        }
    }

    /// <summary>
    /// Handles the ClientSizeChanged event of the ImageViewer control.
    /// </summary>
    void ImageViewer_ClientSizeChanged(object sender, System.EventArgs e)
    {
        UpdateGraphicObjects();
    }

    /// <summary>
    /// Handles the ZoomChanged event of the ImageViewer control.
    /// </summary>
    void ImageViewer_ZoomChanged(object sender, Vintasoft.Imaging.UI.ZoomChangedEventArgs e)
    {
        UpdateGraphicObjects();
    }

    /// <summary>
    /// Handles the ImageLoaded event of the ImageViewer control.
    /// </summary>
    void ImageViewer_ImageLoaded(object sender, Vintasoft.Imaging.ImageLoadedEventArgs e)
    {
        UpdateGraphicObjects();
    }

    #endregion

}
