Imports Vintasoft.Barcode
Imports Vintasoft.Barcode.BarcodeInfo
Imports Vintasoft.Barcode.GS1
Imports Vintasoft.Barcode.SymbologySubsets
Imports Vintasoft.Barcode.TextRendering
Imports Vintasoft.Imaging

Class SSCC18Example
    ''' <summary>
    ''' Generates and recognizes SSCC18 barcode.
    ''' </summary>
    Public Shared Sub Test()
        ' create SSCC18 value
        Dim sscc18Value As GS1ApplicationIdentifierValue = CreateSSCC18Value("0", "460123456", "0000001")

        ' generate barcode image
        Using barcodeImage As VintasoftBitmap = GenerateRasterBitmap(sscc18Value)
            ' save image to file
            ImageCodecs.[Default].Encode(barcodeImage, "sscc18.png")

            ' recognize barcode value
            Dim recognizedValue As GS1ApplicationIdentifierValue = Recognize(barcodeImage)

            ' check value
            If sscc18Value.ToString() <> recognizedValue.ToString() Then
                Throw New ApplicationException()
            End If

            Console.WriteLine("SSCC18 Value:")
            Console.WriteLine("Extension digit         : " & recognizedValue.Value.Substring(0, 1))
            Console.WriteLine("GS1 Company Prefix      : " & recognizedValue.Value.Substring(1, 9))
            Console.WriteLine("Serial reference number : " & recognizedValue.Value.Substring(1 + 9, 7))
            Console.WriteLine("Check digit             : " & recognizedValue.Value.Substring(1 + 9 + 7, 1))
            Console.WriteLine("SSCC18 Printable value  : " & GS1Codec.GetPrintableValue(New GS1ApplicationIdentifierValue() {recognizedValue}))
        End Using
    End Sub

    ''' <summary>
    ''' Creates the value of SSCC18 barcode.
    ''' </summary>
    ''' <param name="extensionDigit">The extension digit.</param>
    ''' <param name="gs1CompanyPrefix">The GS1 Company Prefix number.</param>
    ''' <param name="serialReference">The serial reference number.</param>
    ''' <returns>The SSCC18 barcode value.</returns>
    ''' <remarks>
    ''' The check digit calculates automatically.
    ''' </remarks>
    Public Shared Function CreateSSCC18Value(extensionDigit As String, gs1CompanyPrefix As String, serialReference As String) As GS1ApplicationIdentifierValue
        ' gets SSCC18 Application Identifier
        Dim sscc18Identifier As GS1ApplicationIdentifier = GS1ApplicationIdentifiers.FindApplicationIdentifier("00")

        ' create SSCC18 value (format: N17C)
        Return New GS1ApplicationIdentifierValue(sscc18Identifier, extensionDigit & gs1CompanyPrefix & serialReference & "C")
    End Function

    ''' <summary>
    ''' Generates the SSCC18 barcode image.
    ''' </summary>
    ''' <param name="sscc18Value">The barcode value.</param>
    ''' <returns>The SSCC18 barcode image.</returns>
    Private Shared Function GenerateRasterBitmap(sscc18Value As GS1ApplicationIdentifierValue) As VintasoftBitmap
        ' for Windows
        Vintasoft.Barcode.GdiAssembly.Init()

        ' create barcode writer
        Using writer As New BarcodeWriter()
            ' disable printable value auto letter spacing
            writer.Settings.ValueAutoLetterSpacing = False
            ' set font to default font, 16 pt
            writer.Settings.ValueFont = TextRenderingFactory.[Default].CreateDefaultFont(16)

            ' encode SSCC18 barcode to writer settings
            Dim valueItem As New GS1ValueItem(New GS1ApplicationIdentifierValue() {sscc18Value})
            BarcodeSymbologySubsets.SSCC18.Encode(valueItem, writer.Settings)

            ' generate barcode image
            Return writer.GetBarcodeAsVintasoftBitmap()
        End Using
    End Function

    ''' <summary>
    ''' Recognizes the SSCC18 barcode from image.
    ''' </summary>
    ''' <param name="barcodeImage">The barcode image.</param>
    Private Shared Function Recognize(barcodeImage As VintasoftBitmap) As GS1ApplicationIdentifierValue
        ' create barcode reader
        Using reader As New BarcodeReader()
            ' specify that SSCC18 barcode must be recognizeds
            reader.Settings.ScanBarcodeSubsets.Add(BarcodeSymbologySubsets.SSCC18)

            ' recognize barcode
            Dim info As IBarcodeInfo = reader.ReadBarcodes(barcodeImage)(0)

            ' return SSCC18 value
            Return DirectCast(info.ValueItems(0), GS1ValueItem).ApplicationIdentifierValues(0)
        End Using
    End Function
End Class

using System;
using Vintasoft.Barcode;
using Vintasoft.Barcode.BarcodeInfo;
using Vintasoft.Barcode.GS1;
using Vintasoft.Barcode.SymbologySubsets;
using Vintasoft.Barcode.TextRendering;
using Vintasoft.Imaging;

class SSCC18Example
{
    /// <summary>
    /// Generates and recognizes SSCC18 barcode.
    /// </summary>
    public static void Test()
    {
        // create SSCC18 value
        GS1ApplicationIdentifierValue sscc18Value = CreateSSCC18Value("0", "460123456", "0000001");

        // generate barcode image
        using (VintasoftBitmap barcodeImage = GenerateRasterBitmap(sscc18Value))
        {
            // save image to file
            ImageCodecs.Default.Encode(barcodeImage, "sscc18.png");

            // recognize barcode value
            GS1ApplicationIdentifierValue recognizedValue = Recognize(barcodeImage);

            // check value
            if (sscc18Value.ToString() != recognizedValue.ToString())
                throw new ApplicationException();

            Console.WriteLine("SSCC18 Value:");
            Console.WriteLine("Extension digit         : " + recognizedValue.Value.Substring(0, 1));
            Console.WriteLine("GS1 Company Prefix      : " + recognizedValue.Value.Substring(1, 9));
            Console.WriteLine("Serial reference number : " + recognizedValue.Value.Substring(1 + 9, 7));
            Console.WriteLine("Check digit             : " + recognizedValue.Value.Substring(1 + 9 + 7, 1));
            Console.WriteLine("SSCC18 Printable value  : " + GS1Codec.GetPrintableValue(new GS1ApplicationIdentifierValue[] { recognizedValue }));
        }
    }

    /// <summary>
    /// Creates the value of SSCC18 barcode.
    /// </summary>
    /// <param name="extensionDigit">The extension digit.</param>
    /// <param name="gs1CompanyPrefix">The GS1 Company Prefix number.</param>
    /// <param name="serialReference">The serial reference number.</param>
    /// <returns>The SSCC18 barcode value.</returns>
    /// <remarks>
    /// The check digit calculates automatically.
    /// </remarks>
    public static GS1ApplicationIdentifierValue CreateSSCC18Value(string extensionDigit, string gs1CompanyPrefix, string serialReference)
    {
        // gets SSCC18 Application Identifier
        GS1ApplicationIdentifier sscc18Identifier = GS1ApplicationIdentifiers.FindApplicationIdentifier("00");

        // create SSCC18 value (format: N17C)
        return new GS1ApplicationIdentifierValue(sscc18Identifier, extensionDigit + gs1CompanyPrefix + serialReference + "C");
    }

    /// <summary>
    /// Generates the SSCC18 barcode image.
    /// </summary>
    /// <param name="sscc18Value">The barcode value.</param>
    /// <returns>The SSCC18 barcode image.</returns>
    private static VintasoftBitmap GenerateRasterBitmap(GS1ApplicationIdentifierValue sscc18Value)
    {
        // for Windows
        Vintasoft.Barcode.GdiAssembly.Init();

        // create barcode writer
        using (BarcodeWriter writer = new BarcodeWriter())
        {
            // disable printable value auto letter spacing
            writer.Settings.ValueAutoLetterSpacing = false;
            // set font to default font, 16 pt
            writer.Settings.ValueFont = TextRenderingFactory.Default.CreateDefaultFont(16);

            // encode SSCC18 barcode to writer settings
            GS1ValueItem valueItem = new GS1ValueItem(new GS1ApplicationIdentifierValue[] { sscc18Value });
            BarcodeSymbologySubsets.SSCC18.Encode(valueItem, writer.Settings);

            // generate barcode image
            return writer.GetBarcodeAsVintasoftBitmap();
        }
    }

    /// <summary>
    /// Recognizes the SSCC18 barcode from image.
    /// </summary>
    /// <param name="barcodeImage">The barcode image.</param>
    private static GS1ApplicationIdentifierValue Recognize(VintasoftBitmap barcodeImage)
    {
        // create barcode reader
        using (BarcodeReader reader = new BarcodeReader())
        {
            // specify that SSCC18 barcode must be recognizeds
            reader.Settings.ScanBarcodeSubsets.Add(BarcodeSymbologySubsets.SSCC18);

            // recognize barcode
            IBarcodeInfo info = reader.ReadBarcodes(barcodeImage)[0];

            // return SSCC18 value
            return ((GS1ValueItem)info.ValueItems[0]).ApplicationIdentifierValues[0];
        }
    }
}
